Terraco Terramesh, an EIFS grade glass fibre mesh, is used as a reinforcing mesh to enable the EIFS to withstand up to 10 joules of impact.
| Terramesh - Glass Fiber Mesh E Glass | Technical Properties |
| Weave | Leno |
| Mesh Spacing | 3.5 x 4.0mm |
| Standard Width | 1000mm ±10mm |
| Standard Length | 50m |
| Finished Product Weight | 161 g/m² ±10 DIN 53854 |
| Tensile Strength | ≥ 2000 N/5cm DIN EN ISO 13934-1 |
| Elongation | ≤ 3.9 DIN EN ISO 13934-1 |
| Tear Resistance | High |
| Alkali Resistance | High |
INSTALLATION
The Terramesh is embedded into fresh Styrobond DP basecoat applied at a thickness of 1.5-2.0mm, overlapping 10cm at all edges, and allowed to set. Once cured, and the rest of the System Components (window trims etc.) have been installed, a final coat of Styrobond DP is applied to achieve an overall thickness of 3-4mm, before the decorative finishing can commence.
It is also recommended to:
